Series 43 Attika-Direkt

LORO-X Attika-Direkt drainage systems with adhesive flange for direct installation in the parapet upstand of the roof can be installed either with downpipe and rain standpipe or as a spout without downpipe.

In both cases, you drain your building completely externally, quietly and safely.

Space-saving

Drains of the Series 43 Attika-Direkt are installed space-savingly "directly" in the parapet edge, so that the roof area can be optimally used. This is particularly advantageous for small and used roof areas, such as terraces or accessible flat roofs.

With the matching gravel trap, they adapt optimally to any gravel layers and slab surfaces, so that neither dirt nor stones can get into the drainage.

Silent

For residential and office buildings, the lowest possible noise development of the drainage is often the focus.

The drains of Series 43 were designed to achieve high drainage even with quiet gravity flow. The generous ventilation openings ensure gravity flow and thus prevent the build-up of negative pressure.

To optimally use the interior of the building and not generate any noise inside the building, external pipelines are often preferred.

Patented Design

Through the patented double acceleration of water with the "lowered pipe" and through the patented double pipe principle with less intrusion depth, a roof drainage standard-compliant flow of up to 4.5 l/s with safe silent gravity flow and a water height of only 35 mm is possible - both as a spout and in the complete system.

Adhesive Flange

Due to the naturally rough surface of hot-dip galvanized steel, hot-dip galvanized adhesive flanges are ideally suited for bonding waterproofing membranes or liquid plastics.

The waterproofing can "hold on" better to the rough surface compared to smooth surfaces. This property of the galvanized surface makes the roofer work easier and increases the tightness of the connection.

Advantages

• Roof drainage standard-compliant flow rate up to 4.5 l/s at 35 mm water height
• Silent gravity flow optimal for residential buildings
• Upstand with adhesive flange for easy installation in the parapet upstand
• Can be used as a spout or with downpipe
• Space-saving due to direct installation in the parapet upstand
• Ideal for small to medium-sized areas
