LORO-X Balcony Drains, Series IV

with flexibly positionable mounting ring instead of fixed retaining lugs, for slab thicknesses from 95-220 mm, DN 70

LORO-X Series IV for direct installation in waterproof concrete balconies, hot-dip galvanized steel, DN 70 and DN 100
Aktuell 189 (PDF)

Series IV combines the advantages of Series I with those of Series V with a flexibly positionable mounting ring instead of fixed retaining lugs: This means the insertion angle of the pipe coming from above can be freely chosen during on-site installation!

Standard availability of drains for slab thicknesses from 95-220 mm.

Proven quality: Used in precast concrete applications for over 50 years.

Advantages

  • Bell for invisible reception of the socket
  • With flexibly positionable mounting ring instead of fixed retaining lugs
  • Made of steel, hot-dip galvanized, additionally coated, wall thickness 2 mm
  • Building material class A1 non-combustible for preventive fire protection
LORO Direct Balcony Drains with Bell, Series IV
Slab Thickness DN 50 DN 70 DN 100
95 mm 16345.050X 16345.070X
120 mm 16340.050X 16340.070X 16340.100X
140 mm 16341.050X 16341.070X 16341.100X
160 mm 16342.050X 16342.070X 16342.100X
180 mm 16343.050X 16343.070X 16343.100X
200 mm 16344.050X 16344.070X 16344.100X
220 mm 16346.050X 16346.070X 16346.100X
LORO-X Top Element for Balcony Emergency Drainage
DN 50 DN 70 DN 100
16189.050X 16189.070X 16189.100X
LORO-X Balcony Drain Strainer Unit
DN 50 DN 70 DN 100
with mounting ring, for balcony floors 20422.050X 20422.070X 20422.100X
with mounting ring, for upper balconies 20421.050X 20421.070X 20421.100X
