20435.100XLX-AUFSATZELEMENT M.AUFGEK.KLEBEFL.DN 100 · 2,80 Kg · WG 4 · Edelstahl›
Articolo: 20435.100X – LX-AUFSATZELEMENT M.AUFGEK.KLEBEFL.
LORO-X surface-mounted element with upturned adhesive flange 270 mm long Series V-AK DN 100
Descrizione
LORO-X balcony extension unit for two piece version, series V-AK, with upstanded bonding flange for sealing from liquid plastic at wall areas, according to DIN EN 1253 with raised quality standard, made of stainless steel, consisting of: extension body with upstanded bonding flange and sealing element DN100, made of stainless steel, DN100
- Prezzo export LORO
- 238,10 €
- Codice EAN
- 4038088106181
- Classe ETIM
- EC011398
- Diametro nominale
- DN 100
- Misure esterne (AxLxP)
- 300 x 245 x 366 mm
- Peso
- 2,80 Kg (STK)
- Gruppo prodotti
- 4
- Numero tariffa doganale
- 73072980
- Produktfinder/Serie
- Link
- Materiale / Colore
- Edelstahl, Silber
Note d'uso
LORO-Balkonablauf mit Aufsatzelemente, Serie V-AK für Balkonabdichtung aus Flüssigkunststoffen im Wandbereich. Zweiteilige Ausführung für wärmegedämmte Balkone, mit aufgekanteten Klebeflansch für Einbau in Wand-oder Eckbereichen.
Scheda tecnica del prodotto (PDF)
CAD 2D (DXF)Articoli complementari
Sistemi completi LX
Sistema completo LX 2168-13Xcon tubo pluviale›
Sistema completo LX 2168-13X –
Descrizione
LORO-X balcony extension unit for two piece version, series V-AK, with upstanded bonding flange for sealing from liquid plastic at wall areas, according to DIN EN 1253, with raised quality standard, made of stainless steel, consisting of: extension body with upstanded bonding flange and sealing element DN125, made of stainless steel, strainer for upper balconies, proof of performance according to specification sheet LX 2168, DN100
Distinta base – Scheda tecnica del sistema LX2168-13X
| 1× | | 20435.100X | LX-AUFSATZELEMENT M.AUFGEK.KLEBEFL. | |
| 1× |  | 20426.100X | LORO-X AUFSATZELEM.M.KLEBEFL.SERIE V-FL. | |
| 1× |  | 20430.100X | LORO-X AUFSATZELEM.M.AUGEK,KLEBEFLANSCH, | |
| 1× |  | 20421.100X | LORO-X SIEBEINH.SIEB RUND,OHNE ROHRDUCHF | |
| 1× |  | 00986.000X | LORO-X LUBRICANT 250 G TUBE |
Forme alternative di flangia secondo scheda tecnica del sistema LX2168
Sistema completo LX 2169-13Xcon tubo pluviale›
Sistema completo LX 2169-13X –
Descrizione
LORO-X balcony extension unit for two piece version, series V-AK, with upstanded bonding flange for sealing from liquid plastic at wall areas, according to DIN EN 1253, with raised quality standard, made of stainless steel, consisting of: extension body with upstanded bonding flange and sealing element DN125, made of stainless steel, strainer for pipe opening for balcony floors, proof of performance according to specification sheet LX 2169, DN100
Distinta base – Scheda tecnica del sistema LX2169-13X
| 1× | | 20435.100X | LX-AUFSATZELEMENT M.AUFGEK.KLEBEFL. | |
| 1× | | 20426.100X | LORO-X AUFSATZELEM.M.KLEBEFL.SERIE V-FL. | |
| 1× | | 20430.100X | LORO-X AUFSATZELEM.M.AUGEK,KLEBEFLANSCH, | |
| 1× |  | 20422.100X | LX-SIEBEINH.SIEB RUND,M.ROHRDURCHF.SR.V | |
| 1× | | 00986.000X | LORO-X LUBRICANT 250 G TUBE |
Forme alternative di flangia secondo scheda tecnica del sistema LX2169
Sistema completo LX 2170-13Xcon tubo pluviale›
Sistema completo LX 2170-13X –
Descrizione
LORO-X balcony extension unit for two piece version, series V-AK, with upstanded bonding flange for sealing from liquid plastic at wall areas, according to DIN EN 1253, with raised quality standard, made of stainless steel, consisting of: extension body with upstanded bonding flange and sealing element DN125, made of stainless steel, holding fixture for strainer (for installatin height 35-150 mm), strainer for upper balconies, proof of performance according to specification sheet LX 2170 DN100
Distinta base – Scheda tecnica del sistema LX2170-13X
| 1× | | 20435.100X | LX-AUFSATZELEMENT M.AUFGEK.KLEBEFL. | |
| 1× | | 20426.100X | LORO-X AUFSATZELEM.M.KLEBEFL.SERIE V-FL. | |
| 1× | | 20430.100X | LORO-X AUFSATZELEM.M.AUGEK,KLEBEFLANSCH, | |
| 1× |  | 20424.100X | LX-SIEBEINH.SIEB QUARD.O,ROHRDURCHF.SR.V | |
| 1× | | 00986.000X | LORO-X LUBRICANT 250 G TUBE |
Forme alternative di flangia secondo scheda tecnica del sistema LX2170
Sistema completo LX 2171-13Xcon tubo pluviale›
Sistema completo LX 2171-13X –
Descrizione
LORO-X balcony extension unit for two piece version, series V-AK, with upstanded bonding flange for sealing from liquid plastic at wall areas, according to DIN EN 1253, with raised quality standard, made of stainless steel, consisting of: extension body with upstanded bonding flange and sealing element DN125, made of stainless steel, holdig fixture for strainer (for installation height 35-150 mm), strainer for pipe opening for balcony floors, proof of performance according to specification sheet LX 2171, DN100
Distinta base – Scheda tecnica del sistema LX2171-13X
| 1× | | 20435.100X | LX-AUFSATZELEMENT M.AUFGEK.KLEBEFL. | |
| 1× | | 20426.100X | LORO-X AUFSATZELEM.M.KLEBEFL.SERIE V-FL. | |
| 1× | | 20430.100X | LORO-X AUFSATZELEM.M.AUGEK,KLEBEFLANSCH, | |
| 1× |  | 20423.100X | LX-SIEBEINH.SIEB QUADR.M.ROHRDURCHF.SR.V | |
| 1× | | 00986.000X | LORO-X LUBRICANT 250 G TUBE |
Forme alternative di flangia secondo scheda tecnica del sistema LX2171
